Winbond W29GL family of 3-Volt Page-Mode Parallel Flash memories are offered in densities from 32Mb to 256Mb and support industry standard interfaces, architectures and packages. They are drop-in replacements to the popular “x29GL” products available in the industry, with no firmware change. The W29GL family also offers faster program and erase times, which can improve production throughput and enable faster firmware updates. Winbond Parallel Flash products are ideal for a wide variety of applications requiring the higher performance of a parallel bus width and page mode operation.

pdfParallelFlashProductSelectionGuide020315

Parallel_DevicePF_Erase_ChartPF_Program_Chart

W29GL Page Mode Parallel Flash Family

32Mb to 256Mb densities

Compatible with Industry Standard x29GL products

2.7V to 3.6V operation; also supports VIO at 1.8V

x8/x16 data bus configuration

70/90ns read access time, 25ns page mode access time

Provides many sector protection mechanisms

Offers additional security of code/data

Package Options

Industry standard packages for 32Mb & 64Mb densities

48-pin TSOP (Top/Bottom Boot)

48-ball VFBGA (Top/Bottom Boot)

56-pin TSOP (High/Low Sector protect)

64-ball LFBGA (Top/Bottom Boot, High/Low Sector protect)

Industry standard packages for 128Mb & 256Mb densities

56-pin TSOP (High/Low Sector protect)

64-ball LFBGA (High/Low Sector protect)

Special Features

Provides many sector protection mechanisms

Offers additional security of code/data

Provides many sector protection mechanisms

Offers additional security of code/data

Wide Range of Applications

Networking, Storage, Set-Top-Box, DSL and Cable modems

Wireless routers, Digital TV, Industrial, Automotive

PC peripherals, Printer, Mobile phones, Cameras and more
